    Visaton - Amp 2.1 PM- Stereo + Subwoofer Amplifier Module
    Art. No. 7104

    Description
    12V class-D 2.1 channel loudspeaker power-amplifier module as a sub-assembly for the installation inside of enclosed electronic assemblies. Combined with two full-range loudspeakers and one subwoofer it is able to work as a sub/sat-system. The loudspeaker connections as well as the connection for the power supply are realised with screwable terminal block connectors. A stereo audio signal can be injected via a 3.5 mm jack socket. The volume of the subwoofer output can be adjusted with the blue trimming potentiometer.

    Connection
    With the help of the four mounting holes the module can be installed into a suitable enclosure. The proper connections of the module can be found in the shown connection diagram. To avoid any personal or material damage the power supply should be turned off over the whole duration of the assembly and connection process and connected in the end.

    Important: Due to the risk of short circuits, none of the speaker outputs is allowed to be connected to ground! The module is exclusively allowed to be used and handled by qualified personnel with basic knowledge in electronics.



    Technical Specifications

    Power supply 12V DC / 2A
    Quiescent current 66 mA
    Input impedance 50 kOhm
    Output impedance 0.11 Ohms
    Power utput Sub 1x 12W (4 Ohm)
    1x 6W (8 Ohm)
    1x 3W (16 Ohm)
    Power output Sat 2x 7W (4 Ohm)
    2x 6W (8 Ohm
    2x 3W (16 Ohm)
    Input voltage (full conduction) Sub 300 mV
    Input voltage (full conduction) Sat 700 mV
    Frequency response Sub 20 - 140 Hz
    Frequency response Sat 140 - 20 kHz
    Dimensions 55 x 50 x 23 mm
    Terminal Input Jack 3.5 mm stereo
    Terminal DC / Output Screw terminal blocks
    Net weight 35g
