Soundlabs Group: Mundorf MCap Classic Capacitors

11 Items In Total

Mundorf 0.33uF 630V M-Cap Capacitor **$5.50 each**

Mundorf 0.56uF 630V M-Cap Capacitor **$6.00 each**

Mundorf 0.68uF 630V M-Cap Capacitor **$6.00 each**

Mundorf 0.82uF 630V M-Cap Capacitor **$7.00 each**

Mundorf 1.8uF 400V M-Cap Capacitor **$6.00 each**

Mundorf 2.7uF 400V M-Cap Capacitor **$6.50 each**

Mundorf 8.2uF 400V M-Cap Capacitor **$9.50 each**

Mundorf 56uF 400V M-Cap Capacitor **$38.00 each**

Mundorf 150uF 400V M-Cap Capacitor **$89.00 each**

Mundorf 220uF 400V M-Cap Capacitor **$130.00 each**

Mundorf 330uF 250V M-Cap Capacitor **$165.00 each**

The M-Cap is an audiophile metallised polypropylene capacitor. In selection of the materials used, special attention was given to the sound properties. Great care taken during the production guarantees constant high quality and minimum electrical and mechanical tolerances. The practically induction-free type of construction and the low loss factor of the M-Cap results in a very "quick" capacitor. The M-Cap forms the basis for vivid music reproduction rich in nuance.

The 630V DC versions are equally suitable as a bypass capacitor in high quality frequency crossovers or as a coupling capacitance in valve and transistor amplifiers.

Specifications:

Capacitance range: 0.01 - 330 µF
Voltage rating: 250 / 400 / 630 VDC (Not all voltages available for all values)
Film: Metallised Polypropylene
Tolerance: ± 3% or ± 5%
Loss factor: tan d = 0.0002 (for 1 kHz / 1 µF)

Dimensions:

Mundorf M-Cap capacitor dimensions
